Shallow Geothermal Borefield Verification

50-year system.
Zero subsurface
verification.
Until now.

BoreLogger gives geothermal GSHP projects and thermal energy networks documented proof of what was actually drilled.

▶  Join Early Access ↓  See Sample Report
SCROLL
<5%
Of geothermal GSHP bores are ever deviation-surveyed
3–12°
Typical unmonitored deviation — enough to shift a bottom-hole 25–70ft off target at 500ft depth
50 yr
Geothermal GSHP system design life built on borehole geometry no one has verified
How It Works

Three steps. One survey run.

STEP 01
0 ft 100 ft 200 ft 350 ft 470 ft
Deploy the Probe
Lower the BoreLogger inside the HDPE pipe
→
STEP 02
DEPTH 124 ft
INC 1.2°
AZI 045°
DEPTH 248 ft
INC 2.1°
AZI 048°
INC 3.8° WARN
AZI 315°
Log Every Foot
Retrieve the data when the run is complete.
→
STEP 03
VERIFICATION REPORT
BH-01PASS
BH-05WARN
BH-06PASS
BH-10FLAG
BH-11PASS
TOTAL19/24
Get Your Report
An automated verification report
Who It's For

Different stakes.
Same need for verified geometry.

For Engineers & Designers
Iterate GSHP thermal design on real borehole geometry, not assumptions.
  • Confirm installed spacing and verticality match your geothermal model
  • Feed actual borefield geometry back into your thermal design — not initial theoretical values
  • Specify borehole deviation verification on dense or boundary-adjacent projects
For Project Owners
Know exactly what's underground — and whose property it's on.
  • Verify bores stayed within your property boundary and thermal energy rights
  • Subsurface as-built documentation for your long-term asset records
  • Verification report for commissioning and regulatory handover
For Drilling Contractors
Add borefield verification to your service offering.
  • New differentiated service line for geothermal GSHP and thermal energy network projects
  • Assistant driller can easily deploy on a standard line
  • Deliver professional verification reports to engineering clients
Live Borefield Demo

See the data. Explore the field.

Drag to rotate  ·  scroll to zoom  ·  click a bore to inspect

3D VIEW — DRAG TO ROTATE · SCROLL TO ZOOM
Euclid TEN — 12-Bore Demonstration Field
BORE—
DEPTH—
MAX INC—
DRIFT AZI—
LAT. DEP.—
STATUS—
Euclid TEN demonstration data · 12-bore subset · 20ft bore spacing · 450–480ft depth
What You Get

The subsurface built is missing.

Every survey produces a structured verification report — built for engineers, owners, and regulators.

  • ⬡
    Executive SummaryBore count, avg and max deviation, footprint vs. design.
  • ⬡
    Per-Bore StatusEvery bore: depth, inclination, lateral departure, PASS / WARN / FLAG.
  • ⬡
    Trajectory PlotsPlan view showing actual bore path vs. designed position.
  • ⬡
    Open DataRaw survey data for import into your own analysis tools.
↓  Download Sample Report
BOREFIELD VERIFICATION REPORT
PROJECTEuclid Thermal Energy Network
LOCATIONNew Haven, CT
TOTAL BORES24
AVG INCLINATION2.3°
MAX DEVIATION5.8° — BH-10
PASSED19 PASS
WARNED4 WARN
FLAGGED1 FLAG
VIEW FULL SAMPLE REPORT →
Services

Assumed → measured, in three tiers.

Tier 01 · Geometry

Where the bores actually went.

A 3D as-built survey of every bore — drift, property-line excursions, and collision risk, before they cost you a redrill.

  • True 3D trajectory, foot by foot
  • Bottom-holes flagged when they leave your property
  • A probabilistic drilling plan & bore-by-bore sequence
Property boundary
Bottom hole off-property
✕ Collision · $65/ft redrill
Tier 02 · Capacity

What that does to your capacity.

We recompute the field’s real thermal capacity on the measured geometry — the gain or loss the vertical design never saw. Critical for dense Cold-UTES for data-center cooling fields, where clustering quietly kills capacity.

  • As-built g-function on the measured field
  • Thermal interference mapped, depth by depth
  • Capacity gain or loss vs the vertical design
as-built g-function
Tier 03 · Conductivity

Measured, not assumed.

A Thermal Response Test with fiber-optic DTS logging — measured conductivity at every depth, and the groundwater and grout voids a single bulk number hides.

  • A conductivity profile, not an average
  • Groundwater and grout-void flags by depth
  • A capacity number you can size the plant on
measured λ(z) · 0.6–3.4 W/m·K
Add-on · consulting
Drilling Consulting
Not a measurement — a service. For flagged bores or persistent deviation, we bring in directional-drilling specialists - MA, CT, NY, NJ certified - for corrective action and drilling optimization.
Talk to us →
Early Access Program

We're working with a small number of engineers and drillers on early pilots. Join to get priority access

✓ You're on the list.

We'll be in touch about early access and pilot opportunities.
